Industrial router ICR-2031W for communication in 4G/LTE networks, with Wi-Fi
The Advantech ICR-2031W industrial LTE router is designed for reliable wireless communication in LTE networks. With LTE Cat.4 certification, it delivers high data transfer speeds of up to 150 Mbps (downlink) and 50 Mbps (uplink). It is an ideal choice for deployment in areas with 4G coverage, where, when utilizing 20 MHz contiguous spectrum, it ensures stable and fast data connectivity.
Typical use cases of the ICR-2031W
The ICR-2031W router is a versatile solution for IoT projects. It is suitable for applications requiring high reliability, such as payment terminals, intelligent transportation systems, remote monitoring of UPS systems, and large-scale sensor networks.
Connectivity, Wi-Fi and advanced security
- Wired interfaces and I/O: The device is equipped with an Ethernet port (10/100 Mbps) and digital inputs/outputs (1× DI, 1× DO) for direct integration of sensors and peripherals.
- Flexible Wi-Fi: The integrated 802.11b/g/n module supports AP, Station, and Multirole modes, enabling wireless connection of devices without the need for cabling.
- High security: Maximum protection of transmitted data is ensured through broad support for VPN protocols for creating secure encrypted tunnels.
- Stability and continuity: Continuous operation is maintained by intelligent diagnostics and an integrated hardware watchdog that constantly monitors system status.
ICR-OS operating system and expandability
The router runs on the Linux-based ICR-OS operating system. This open platform allows developers to create custom software applications in C/C++. Standard firmware functionality can be easily extended using the freely available RouterApps library, which includes ready-made applications designed to enhance specific router functions in industrial environments.
Industrial design and high durability
The device is housed in a durable metal enclosure with IP30 protection and is designed to operate in extreme temperature conditions ranging from –40 °C to +75 °C.
Key features:
- Compact and robust design
- LTE Cat.4 with 3G/2G fallback connectivity
- 1× SIM card slot
- Interfaces: 1× Gigabit Ethernet port (10/100 Mbps), 1× Wi-Fi 802.11b/g/n
- Remote management: full compatibility with WebAccess/DMP for mass configuration and monitoring
- High durability: industrial-grade metal design with a wide operating temperature range from -40 °C to +75 °C
- Dimensions: 103 × 95 × 25 mm
- Weight: 335 g
- Wall or DIN rail mounting
Package contents:
- Advantech ICR-2031W router
- 1× 6-pin connector
- Mounting bracket
Technical information can be found in the attached datasheet.
