Robustel LTE Router R2110-4L, Cat 6, fw 3.1.0, no BT
The Robustel R2110-4L LTE Cat 6 is a robust cellular router that offers state-of-the-art mobile connectivity for Internet applications.
The R2110 router supports a wide range of Internet connections, including Ethernet, Wi-Fi and 4G LTE. With its wide range of functions, robust design and IP30, it is suitable for use in demanding environments. The router can be easily mounted on a DIN rail, making it easy to install in engineering or industrial facilities.
Of course, R2110, like all Robustel devices, includes RobustOS, an operating system developed on Linux that makes it easy to implement and develop countless applications. The R2110 comes with a complete SDK and full Robustel app development support for larger projects.,
This router does not include a Bluetooth interface.
Key Features:
• 1Gbps faster ethernet port
• 802.11ac Wave1 dual 2.4G & 5GHz
• GNSS GPS/GLONASS/BeiDou/Galileo
• POE power supply for bottom equipment
• RS485&RS232 serial interface
• DI/DO trigger switch
• Supports WWAN, WAN, WLAN link backup and ICMP detection
• Supports cold backup , warm backup and load balancing
• RobustOS + SDK + App
• IPsec/OpenVPN/GRE
• Management and maintenance via Web/CLI/SNMP/RobustLink Cloud
• Robust industrial design (9 to 36V DC, desktop or wall mounting or DIN rail mounting)
Package included:
• 1x 3-pin connector
• 2x 5-pin connector
Antennas, power supply and Ethernet cable are not included.
SECTRON recommends to buy the following accessories:
AM-RT-FPOWR - Power supply 12V / 1A, L=1.4m, w/o connector, open end
AM-R3000-L-MRT - R3000-Litepower connector 3-pin
FSMAK3 - Antenna GSM/UMTS/LTE FLAT Stick 90°/180°, 690-2700 MHz, 3 dBi, SMA(m)
FSMAK - Antenna GSM/UMTS/LTE FLAT Stick 90°/180°, 698-2700 MHz, 3 dBi, SMA(m)
AP-AGNSS-A002S - Antenna GPS/GLONASS Adhesive 002, SMA(m), RG174/3m
AM-RT-ETH150-CAT5E - Ethernet cable CAT5e, RJ45/RJ45, Grey, 1.5m
*Optional accessories
AO-ALTE-MG9S - Antenna GSM/UMTS/LTE Magnetic 90, 5-9 dBi, SMA(m), 3m RG174 – (3m)
AO-ALTE-MG9S5 - Antenna GSM/UMTS/LTE Magnetic 5-9 dBi, SMA(m), 5 m RG174U-DS – (5m)
Product Video
The product video will provide you with information about the features of the Robustel R2110 router and present specific examples of use.
More information can be found in the attached datasheet.
